Sauter THM Motorised Test Stands
Easy to use motorised test stand with a robust design and heavy duty metal construction. Capacity: up to 500 Newtons (standard); Maximum tensile and compressive force: 500 N (Standard); THM Foil Special for peel-off tests up to size DIN A4. Can be used with force gauge models up to 500 N Max.
KERN THM-N:
  • Minimum distance between left and right object fastening: 30 mm
  • Maximum travel length: 220 mm (protected by electronic end switches)
  • Overall dimensions W×D×H 550×170×345 mm
  • Net weight approx. 33 kg
  • KERN THM-S:
  • Maximum travel length: 240 mm (protected by electronic end switches)
  • Overall dimensions W×D×H 235×300×695 mm
  • Net weight approx. 48 kg

Sauter THM Motorised Test Stands:
Maximum tensile and compressive force: 500 N (Standard)
Closest starting point of the carriage from the instrument: 30 mm
Maximum length of travel: 220 mm (protected by electronic end switches)
Overall dimensions LxWxH 550x170x345 mm
Net weight approx. 35 kg


Model
Measuring Capacity
(Max) N
Speed Range
mm/min
Motor
 THM 500N500N 500   50-500  Electric motor
THM 500N500S  500   1-500 Step motor
