Straightpoint Insight Software
461.00
(553.20 Incl. VAT)
Save £66.00
Item in Stock
(0 review)
Straightpoint INSIGHT software, supplied with an SW-D USB wireless dongle, allows connection of up to 126 Straightpoint wireless load cells simultaneously onto any Windows tablet or laptop.
INSIGHT has three main features:
1. Multi-channel display and data logging mode – view and log load data from connected load cells plus totals loads live on screen and directly into a .csv file for later analysis at speeds of up to 200Hz.
2. Visualisation mode – For complicated lifts import a photo of the lift and drag and drop load cell displays – make the screen look like the lift.
3. Centre of gravity mode – Connect to SP’s range of wireless compression load cells and use this feature to weigh and calculate the centre of gravity of large items and structures.
FEATURES
• Logging at timed intervals, manual or on
overload/underload
• Visual and audible alarms indicate overload,
underload, low battery and communications
error
• Zoom in to individual load cell to see data
trends and history
• 100% wireless, no easily damaged cables
• 700m or 2300ft range
INSIGHT has three main features:
1. Multi-channel display and data logging mode – view and log load data from connected load cells plus totals loads live on screen and directly into a .csv file for later analysis at speeds of up to 200Hz.
2. Visualisation mode – For complicated lifts import a photo of the lift and drag and drop load cell displays – make the screen look like the lift.
3. Centre of gravity mode – Connect to SP’s range of wireless compression load cells and use this feature to weigh and calculate the centre of gravity of large items and structures.
FEATURES
• Logging at timed intervals, manual or on
overload/underload
• Visual and audible alarms indicate overload,
underload, low battery and communications
error
• Zoom in to individual load cell to see data
trends and history
• 100% wireless, no easily damaged cables
• 700m or 2300ft range
Global Specifications - Insight Software |
|
Part number |
INSIGHT |
Crosby Part number |
2789318 |
USB Dongle Operating temperature |
-20°C to 55°C or -4°F to 131°F |
Licence |
Licence free |
Wireless Frequency |
2.4GHz |
Wireless Range |
700 metres or 2300 feet |
Loadcell inputs |
Up to 126 |
PC requirements |
Intel i3 processor with 2 gb RAM. |
Operating system |
Windows 7 , Windows 8, windows10 |
