Systec IT6000E Average Weight System

Name: Oakleyweigh
Address: Unit 4 Ladymead Business Park, Quainton, Buckinghamshire, HP22 4AN, UK
Telephone: 01296 393133
Price range: $$
Rating: 5

2,615.00

(3,138.00 Incl. VAT)

Item in Stock

(0 review)

System Selection *

Systec IT6000E Controller with Average Weight Software- Standard Enclosure +£2,370.00 (+£2,844.00 Incl. VAT)

Choose Weigh Platform *

SA-3 230 x 230 x 85mm (Capacity 3kg) +£245.00 (+£294.00 Incl. VAT)

S Series SAX-6 300 x 300 x 110mm (Capacity 6kg) +£295.00 (+£354.00 Incl. VAT)

S Series SAX-15 300 x 300 x 110mm (Capacity 15kg) +£295.00 (+£354.00 Incl. VAT)

S Series SAX-30 300 x 300 x 110mm (Capacity 30kg) +£295.00 (+£354.00 Incl. VAT)

S Series SBX-6 400 x 400 x 130mm (Capacity 6kg) +£345.00 (+£414.00 Incl. VAT)

S Series SBX-15 400 x 400 x 130mm (Capacity 15kg) +£345.00 (+£414.00 Incl. VAT)

S Series SBX-30 400 x 400 x 130mm (Capacity 30kg) +£345.00 (+£414.00 Incl. VAT)

S Series SFX-30 500 x 400 x 130mm (Capacity 30kg) +£445.00 (+£534.00 Incl. VAT)

S Series SFX-60 500 x 400 x 130mm (Capacity 60kg) +£445.00 (+£534.00 Incl. VAT)

S Series SFX-150 500 x 400 x 130mm (Capacity 150kg) +£445.00 (+£534.00 Incl. VAT)

Add Calibration Certificate

Calibration Certificate (only if ordered with scale) +£45.00 (+£54.00 Incl. VAT)

About the Systec IT6000E Average Weight System

IT6000E SQC is an IP69 rated checkweighing terminal for the capture and evaluation of samples in compliance with the Regulations for Prepackaged Goods. Operator prompting with clearly structured on-screen menus ensures fast and error-free operation and minimum training requirements. Product file for up to 250 products with automatic allocation of permissible tolerances. Checkweighing results of samples and batch are indicated with colored marking on the TFT display. Ability to record data in the indicator memory and then upload it later to a USB drive or over the network to a host PC. Indicator compact stainless steel IP65 housing. System includes wet cover; SQC application for Average weight programme; USB socket; S Series SAX 300 x 300mm weigh platform (other sizes and capacities available). System can be Trade Approved to 3000 divisions (see chart below).
Choice of IP rated single cell all stainless weigh platforms. Platforms supplied with column which can be fitted on the short side of the platform. A top fixing bracket for a display terminal is available as an option. Full instructions for set up supplied with system. Touch screen indicator available as an option.
A range of options for the SysTec IT6000E programmable controller. More options are available, please call 01296 393133 for further information.

ADM, Analog Scale Interface
DAU15 Analog Output Module 0-20mA / 0-10 VDC
Dual-ADM, Dual Scale Interface
DUAL-ISM Dual-channel fast pulse counter input
Ethernet socket for ITx000E
PIM I/O Module 2 in / 2 out 24 VDC
Relay/Transistor Module 8 I/O - no power supply or enclosure
Relay/Transistor Module 8 I/O- power supply included all in a stainless
Relay/Transistor Module 8 I/O- power supply included, no enclosure
SIM RS232 or SIM RS485.4 Serial Interface options
Splash Guard Wet Cover
USB Socket Type A

Systec IT6000E Average Weight System

Essential features:

Product file for up to 250 products with automatic allocation of permissible tolerances compliant to the regulations and the option to set narrower tolerances

Entry of tare weight or series of tare weighings with calculation of mean value

Independent evaluation of identical products at up to 20 production lines

3 different check methods: individual, additive and 2-phase

Printout of sample and/or batch results on printer with 40 or 80 columns printing width. Optional data transmission of results to host system

Ring buffer for statistics with 500 entries, eg for the last 100 days with 5 products per day; evaluation and printout by product and period.

External USB socket and PC-based data management software.

Rapid and precise checks:
Fast signal processing with more than 200 updates / sec.
High W&M approved resolution of 6000d
Automatic capturing of weight and tolerance zone when scale is settled.
Automatic allocation of tolerance zones according to selected check method (prepackaged goods / pharmacopeia)
Tare weighing or calculation of average tare weight.
Operator is guided on a high contrast colour TFT display
Numeric data entry

Model	Platform Size (mm)	Capacity (kg)	Division Trade Approved (g)	Division Standard (g)	IP Rating
SAX-3	300 x 300 x 110	3	1	0.5	67
SAX-6	300 x 300 x 110	6	2	1	67
SAX-15	300 x 300 x 110	15	5	2	67
SBX-6	400 x 300 x 130	6	2	0.5	67
SBX-15		15	5	1	67
SBX-30		30	10	2	67
SFX-30	500 x 400 x 130	30	10	2	69K
SFX-60		60	20	5	69K
SFX-150		150	50	20	69K
SFX-300		300	100	50	69K
SLX-60	600 x 500 x 150	60	20	5	69K
SLX-150		150	50	10	69K
SLX-300		300	100	50	69K
SXLX-150	800 x 600 x 150	150	50	20	69K
SXLX-300	800 x 600 x 150	300	100	50	69K

C3 approved stainless steel load cell

Heavy duty 'X' shaped construction

Column mounted on short side

370mm circular column on the SAX and SBX models, 650mm box section colum on larger sizes (top bracket not included)

SBX IP67 rating. SFX,SLX, SXLX IP69K rating

SXLX size pallet delivery only

There are no reviews for this product.
Write a review

Shipping Information

Shipping to the Scottish Highlands and Islands, Northern Ireland and the Republic, Isle of Wight and the Isle of Man include an additional cost per order based on product weight. Please contact us for details. Call 01296 393133.

Systec IT6000E SQC Brochure
