A&D BM Micro, Semi-Micro & Analytical Balances

About the A&D BM Micro, Semi-Micro & Analytical Balances

The A&D BM Micro, Semi-Micro and Analytical Balances have a built-in DC static eliminator which can eliminate static electricity from the weighing sample before the measurement, reducing weighing error. Memory function to store weighing data (Max. 200) and calibration data and Interval mode to store the weighing data periodically. A built-in clock and calendar that can add the time and date to the output data. Automatic self calibration, using the internal mass, adapting to changes in temperature. Response adjustment adapting to drafts and/or vibration automatically. Underhook, for measuring density and weighing magnetic materials. Multiple weighing units with most of the common units used around the world.
Gram, Milligram, Counting mode, Percent mode, Ounce (Avoir), Troy Ounce, Metric carat, Momme, Pennyweight, Grain (UK), Tael (preset in the factory), Tola (India), Messghal.
BM-22 is equipped with a smart range function to weigh with the precision range (a higher resolution) when zeroing a tare weight within the weighing capacity. A test tube holder is included in the accessories of BM-20 and BM-22.
Density mode for calculating the density of a solid. BM series balances are equipped with an RS-232C serial interface and a USB interface to communicate with a computer. Communications between the BM series balance using the RS-232C interface and a Windows computer using the Windows communication tools software (WinCT) make building a system very easy. The weighing data can be stored by connecting the accessory data logger (AD-1688) directly, when not using a computer. Good laboratory practice (GLP) / Good manufacturing practice (GMP) data can be output usingthe RS-232C serial interface.

A&D BM Micro, Semi-Micro & Analytical Balances Specifications:

• Easy, fan less static elimination using a built-in ionizer
• Better operability with a large weighing chamber
• Inter-lockable slide doors allowing efficient operation with both hands
• Automatic calibration with an internal mass
• Clearly visible, white-backlit LCD
• Built-in temperature, humidity, and atmospheric pressure sensors
• RS-232C and Quick USB interfaces as standard
• AD-1688 weighing data logger as a standard accessory
• Special pans/holder available for elemental analyses, PM filters, and microfuge tubes (BM-20/22)
• Optional pipette accuracy testing kit (BM-20/22)
• External Input/OutputRS-232C interface
• Quick USB interface LAN – Ethernet interface with WinCT-Plus software (optional)

Model	Capacity	Division	Pan Size	Code
BM-5	5.2g	1μg	Ø 25mm	BM-5
BM-5D	2.1g/5.2g	0.01mg/1μg	Ø 25mm	BM-5D
M-20	22g	0.001mg	Ø 25mm	BM-20
BM-22	5.1g/22g	0.001mg/0.01mg	Ø 25mm	BM-22
BM-252	250g	0.01mg	Ø 90mm	BM-252
BM-200	220g	0.1mg	Ø 90mm	BM-200
BM-300	320g	0.1mg	Ø 90mm	BM-300
BM-500	520g	0.1mg	Ø 90mm	BM-500
